① Place the link module on the bottom of the motor starter protector. Insert the hooks into the
hooking openings on the motor starter protector. Insert the connectors into the corresponding
main conductor terminals.
Mounting
7.3 Assembly and disassembly with dierent mounting systems
SIRIUS 3RA Load Feeders
Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004 77
