② Screw the main conductor terminals tight.
③ Unscrew the main conductor terminals of the contactor fully.
④ Insert the motor starter protector with mounted link module and hooks into the hooking openings
on the contactor. Insert the connectors on the link module into the corresponding main conductor
terminals at the same time. A swivel action is required for this.
⑤ Screw the main conductor terminals tight on the contactor.
⑥ Place the feeder on the DIN rail adapter.
⑦ Screw the feeder to the DIN rail adapter. The feeder sits tight on the adapter.
Tightening torque: 1.2 ... 1.5 Nm
Note
For vibration and shock requirements, the washer must be replaced with a wedge lock washer
(DIN 50021-SS 4.4 x 9.0 x 1.7).
Disassembling the feeder from the DIN rail adapter
To disassemble the feeder, unscrew the screws and pull the feeder down to remove it.
Mounting
7.3 Assembly and disassembly with dierent mounting systems
SIRIUS 3RA Load Feeders
78 Equipment Manual, 02/2022, A5E03656507520A/RS-AC/004
