SIRIUS 3RT2 contactors/contactor assemblies
2.7 Accessories
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
155
2.7 Accessories
2.7.1 Accessories overview
SIRIUS contactors with a width of 45 mm (size S00/S0) come with a uniform, versatile range
of auxiliary switches and accessories, which are quick to retrofit and replace. The
accessories for contactor relays and power contactors are identical in design. The
accessories can be attached on the front or the sides of devices.
The 3RH2 contactor relays can be expanded to give versions with a maximum of 8 poles by
attaching 2-pole or 4-pole auxiliary switch blocks.
Table 2- 22 Overview - Accessories for 3RT2 power contactors and 3RH2 contactor relays
Accessories 3RH2 contactor
relay (size S00)
3RT2 power
contactor (size S00)
3RT2 power
contactor (size S0)
Auxiliary switch blocks on the front/lateral ✓ / --- ✓ / ✓ ✓ / ✓
Auxiliary switch blocks on the front/lateral, solid-state
compatible
✓ / --- ✓ / ✓ ✓ / ✓
Surge suppressor ✓ ✓ ✓
EMC interference suppression module ✓ ✓ ---
OFF-delay device ✓ ✓ ✓
Mechanical latch --- --- ✓
Additional load module ✓ ✓ ---
Control kit for manual operation of contactor contacts ✓ ✓ ---
Coupling link for PLC --- --- ✓
LED display indicator module ✓ ✓ ✓
Solder pin adapter ✓ ✓ ---
Coil terminal module --- --- ✓
Cover for ring cable lug ✓ ✓ ✓
Sealable cover ✓ ✓ ✓
3-phase infeed terminal --- ✓ ✓
Parallel switching connector ✓ ✓ ✓
Link module for two contactors in series --- ✓ ✓
Link module for motor starter protector --- ✓ ✓
Insulating stop ✓ ✓ ✓
1)
Terminal module for contactors with screw connections --- ✓ ✓
Pneumatic timer --- --- ✓
Function modules for
ï‚· Time-delayed switching of contactors
ï‚· Switching over from star operation to delta
operation
--- ✓ ✓
Function modules for connection to the automation
level (AS-Interface or IO-Link)
--- ✓ ✓
Assembly kit for reversing contactor assembly --- ✓ ✓
