Siemens SIRIUS 3RT2.1 Series System Manual

System overview
1.9 Connection
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
85
1.9.3 Image database
Internal circuit diagrams
You can find the internal circuit diagrams for SIRIUS Innovations products online in the
image database (www.siemens.com/lowvoltage/bilddb
).
Enter the order number of the device in the "Order number" field and, in the "Type of object"
selection menu on the left-hand side, select "Unit wiring diagram".
Figure 1-37 Image database
