Siemens SIRIUS 3RT2.1 Series System Manual

SIRIUS 3RV2 motor starter protectors
4.10 Technical data
SIRIUS Innovations
456 System Manual, 01/2011, A8E56203870002-03
4.10.3 Rated data for auxiliary and signaling switches
Transverse auxiliary switch with Type 3RV29 Lateral auxiliary switch with
1 NO + 1 NC, 2 NO, 2 NC,
2 NO + NC
Signaling
switch
1 CO contact 1 NO + 1 NC,
2 NO
Max. rated voltage
 Acc. to NEMA (UL)
V AC 600 250
 Acc. to NEMA (CSA)
V AC 600 250
Continuous current A 10 10 5 2.5
Switching capacity 1 NO + 1 NC, 2 NO, 2 NC:
A600, Q300;
2 NO + 2 NC: A300, Q300
A600,
Q300
B600, R300 C300, R300
4.10.4 Auxiliary switches, front-mounted, transverse
Switching capacity for different voltages
1 CO contact 1 NO + 1 NC, 2 NO
Rated operational current I
e
 AC-15, alternating voltage
- 24 V A 4 2
- 230 V A 3 0.5
- 400 V A 1.5 --
- 690 V A 0.5 --
 AC-12 = I
th
, alternating voltage
- 24 V A 10 2.5
- 230 V A 10 2.5
- 400 V A 10 --
- 690 V A 10 --
 DC-13, direct voltage L/R 200 ms
- 24 V A 1 1
- 48 V A -- 0.3
- 60 V A -- 0.15
- 110 V A 0.22 --
- 220 V A 0.1 --
V 17 Minimum load capacity
mA 1
