Siemens SIRIUS 3RT2.1 Series System Manual

SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
235
Type 3RT2015...16 3RT2017...18
Size S00
Actuation
Switching times
1)
Total break time = opening delay + arcing time
 AC operation at 0.8 to 1.1 x U
s
- Closing delay ms 9 to 35 8 to 33
- Opening delay ms 3.5 to 14 4 ... 15
 DC operation at 0.85 to 1.1 x U
s
- Closing delay ms 30 to 100
- Opening delay ms 7 to 13
 Arcing time
ms 10 to 15
Switching times at 1.0 x U
s
1)
 AC operation
- Closing delay ms 9.5 to 24 9 to 22
- Opening delay ms 4 to 14 4.5 to 15
 DC operation
- Closing delay ms 35 to 50
- Opening delay ms 7 to 12
1)
The OFF-delay times of the NO contacts and the ON-delay times of the NC contacts increase if the contactor coils are
attenuated against voltage peaks (suppression diode 6x to 10x; diode combinations 2x to 6x; varistor +2 to 5 ms).
