Siemens SIRIUS 3RT2.1 Series System Manual

SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
238 System Manual, 01/2011, A8E56203870002-03
Type 3RT2015 3RT2016 3RT2017 3RT2018
Size S00
Main circuit - Current carrying capacity for alternating current
Switching of gas discharge lamps with correction
Per main current path at 230 V
 Shunt compensation with inductive ballast, rated power per
lamp/capacitance/rated operational current per lamp
L 18 W/4.5 μF/0.11 A Qty. 17 22 29 39
L 36 W/4.5 μF/0.21 A Qty. 15 19 21
L 58 W/7.0 μF/0.32 A Qty. 10 14
L 80 W/7.0 μF/0.49 A Qty. 6 9
 With solid-state ballast
4)
single-lamp
L 18 W/6.8 μF/0.10 A Qty. 49 63 84 112
L 36 W/6.8 μF/0.18 A Qty. 27 35 46 62
L 58 W/10 μF/0.29 A Qty. 16 21 28 38
L 80 W/10 μF/0.43 A Qty. 11 14 19 26
 With solid-state ballast
4)
two-lamp
L 18 W/10 μF/0.18 A Qty. 27 (≙ 2 x 27
lamps)
35 (≙ 2 x 35
lamps)
46 (≙ 2 x 46
lamps)
62
(≙ 2 x 62
lamps)
L 36 W/10 μF/0.35 A Qty. 14 (≙ 2 x 14
lamps)
18 (≙ 2 x 18
lamps)
24 (≙ 2 x 24
lamps)
32
(≙ 2 x 32
lamps)
L 58 W/22 μF/0.52 A Qty. 9 (≙ 2 x 9
lamps)
12 (≙ 2 x 12
lamps)
16 (≙ 2 x 16
lamps)
21
(≙ 2 x 21
lamps)
L 80 W/22 μF/0.86 A Qty. 5 (≙ 2 x 5
lamps)
7 (≙ 2 x 7
lamps)
9 (≙ 2 x 9
lamps)
13
(≙ 2 x 13
lamps)
Utilization category AC-5b, switching incandescent lamps
Per main current path at 230/220 V kW 1.3 1.7 2.2 3
