Siemens SIRIUS 3RT2.1 Series System Manual

SIRIUS 3RT2 contactors/contactor assemblies
2.8 Technical data
SIRIUS Innovations
246 System Manual, 01/2011, A8E56203870002-03
Type 3RT2023...25 3RT2026...28
Size S0
Actuation
Switching times at 0.8 to 1.1 x U
S
1)
Total break time = opening delay + arcing time
 AC operation
- Closing delay ms 9 ... 38 8 ... 40
- Opening delay ms 4 ... 16
 DC operation
- Closing delay ms 50 ... 170 50 ... 170
- Opening delay ms 15 ... 17.5
 Arcing time
ms 10
Switching times at 1.0 x U
s
1)
 AC operation
- Closing delay ms 10 ... 18 10 ... 17
- Opening delay ms 4 ... 16
 DC operation
- Closing delay ms 55 ... 80
- Opening delay ms 16 ... 17
1)
The OFF-delay times of the NO contacts and the ON-delay times of the NC contacts increase if the contactor coils are
attenuated against voltage peaks (varistor + 2 ms to 5 ms, diode combination: 2x to 6x).
Table 2- 87 Actuation - 3RT202.-.NB3, 3RT202.-.NF3, 3RT202.-.NP3 contactors
Type 3RT202.-.NB3 3RT202.-.NF3 3RT202.-.NP3
Size S0
Actuation
Magnet coil operating range AC/DC 0.7 to 1.3 x U
S
Magnet coil power input (for cold coil and 1.0 x U
S
)
 AC operation, 50 Hz, UC version
- Switch-on power VA 6.5/5.7 13.6/13.2 16.1/15.9
- cos ϕ 0.98/0.96 0.98/0.99 0.99/0.99
- Holding power VA 1.26/1.3 1.91/1.9 3.41/3.58
- cos ϕ 0.78/0.8 0.61/0.61 0.36/0.45
 DC operation, UC version
- Switch-on power W 6.7 13.2 15
- Holding power W 0.8 1.56 1.83
Permissible residual current of electronics (with 0 signal)
 AC operation
mA < 7 mA x (230 V/U
S
)
 DC operation
mA < 16 mA x (24 V/U
S
)
