SIRIUS 3RT2 contactors/contactor assemblies
2.9 Dimension drawings (dimensions in mm)
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
289
3RT2.1-4. contactors and 3RH21..-4 contactor relays (4-pole) with ring cable lug connection system
and accessories mounted












1 Laterally mountable auxiliary switch block 3RH2911-4DA..
2 Auxiliary switch block for mounting on the front 3RH2911-4FA.. / -4GA.. / -4HA.. / -4NF..
Figure 2-41 3RT2.1-4. contactor and 3RH21..-4 contactor relay (ring cable lug connection system)
with auxiliary switch blocks mounted
Latched 4-pole contactor relay 3RH24..-1 in screw-type connection system





Figure 2-42 Latched 4-pole contactor relay 3RH24..-1 (screw-type connection system)
3RH24..(0LA0) contactor relay with extended operating range in screw-type connection system






Figure 2-43 3RH24.. contactor relay with extended operating range (screw-type connection system)
