SIRIUS 3RV2 motor starter protectors
4.10 Technical data
SIRIUS Innovations
System Manual, 01/2011, A8E56203870002-03
469
"Manual motor controller", group installation
3RV2 motor starter protector as "Manual Motor Controller"
Upstream short-circuit protection is always implemented if the motor starter protector is used
as a "Manual Motor Controller". This requires approved fuses (according to UL 248) or a
circuit breaker (according to UL 489/CSA C22.2 No. 5-02). These devices must be
dimensioned according to the National Electrical Code (UL) or Canadian Electrical Code
(CSA) installation regulation respectively.
The file numbers for the approval of the 3RV as a manual motor controller are as follows:
● UL File No. 47705, CCN: NLRV
● CSA Master Contract 165071, Product Class: 3211 05
Motor starter protector hp-rating
1)
for FLA
2)
max.
Type V 1-phase 3-phase
Size S00
3RV20 11, 3RV21 11, 3RV23 11, 3RV24 11
115 1 2
200 2 3
230 2 5
460 -- 10
FLA
2)
max. 16 A, 480 V
12.5 A, 600 V
575/600 -- 10
Size S0
3RV20 21, 3RV21 23, 3RV23 21, 3RV 21, 3RV24 21
115 3 5
200 5 10
230 7 1/2 10
460 -- 30
FLA
2)
max. 40 A, 480 V
575/600 -- --
1)
hp-rating= power in horse power(maximum motor power).
2)
FLA= Full Load Amps/motor full-load current
240 V AC 480 V AC 600 V AC Rated current
UL CSA UL CSA UL CSA
In Ibc Ibc Ibc Ibc Ibc Ibc
A kA kA kA kA kA kA
Size S00
0.16 ... 1.25 65 65 65 65 30 30
1.6 65 65 65 65 30 30
2 65 65 65 65 30 30
2.5 65 65 65 65 30 30
3.2 65 65 65 65 30 30
