1.10 Connection to the higher-level control

SIRIUS Innovations

92 System Manual, 01/2011, A8E56203870002-03

SIRIUS 4SI electronic module

Ideally suited to connecting SIRIUS Innovations products to IO-Link is the IO-Link master for

SIRIUS controls: the SIRIUS 4SI electronic module for SIMATIC ET 200S.

The SIRIUS 4SI electronic module facilitates the efficient and space-saving integration of IO-

Link-capable SIRIUS switching devices into the TIA world. It connects up to 16 SIRIUS load

feeders to the higher-level control environment.

Table 1- 37 SIRIUS 4SI electronic module

Area Customer benefits

Functions

 Integration of IO-Link-capable SIRIUS

controls in the distributed I/O ET 200S.

 Diagnostics data.

 Status display and group fault signaling.

Dimensioning and design

 Width 15 mm.

 4 IO-Link ports.

 Connection of up to 16 load feeders.

Mounting advantages

 Considerably reduced wiring and space

requirements in the control cabinet.

 Terminal modules with screw-type, spring-

loaded, and insulation displacement

connection system.

Application areas/customer benefits

 Considerably lower price (50%) than the IO-

Link master if only SIRIUS devices are used.

 Reduced wiring

(5 cable connections for 4 feeders).

 Fast module selection via the ET 200

configurator.
