Diagnosis
Diagnostics using STARTER
6-208
E Siemens AG, 2004. All rights reserved
SINAMICS S120 Installation and Start-Up Manual, 12/04 Edition
Note
Please refer to the online help for more information about parameterizing and
using the measuring sockets.
Properties
S Four recording channels per recorder
S Two independent trace recorders per Control Unit
S Triggering
– Without triggering (recording immediately after start)
– Triggering on signal with edge or on level
– Trigger delay and pretrigger possible
S STARTER parameterization and commissioning tool
– Automatic or adjustable scaling of display axes
– Signal measurement via cursor
S Variable trace cycle: integer of basic sampling time
(see also: System Sampling Times, Section 7.7)
Parameterization
The “trace function” parameter screen is selected via the following icon in the tool-
bar of the STARTER commissioning tool.
Fig. 6-7 STARTER icon for “trace function/ramp-function generator”
