Commissioning
Initial commissioning using vector (booksize) as an example
3-62
E Siemens AG, 2004. All rights reserved
SINAMICS S120 Installation and Start-Up Manual, 12/04 Edition
3.5.4 Commissioning with STARTER (example)
The table below describes the steps for commissioning the example with
STARTER.
Table 3-7 Commissioning sequence with STARTER (example)
What to do?
How to do it? Comments
1. Automatic
configuration
Operator action:
–> “Project” –> “Connect to target system”
–> Double-click “Automatic configuration”
–> Follow the instructions provided in the Wizard
2. Configure
drives
The drives must be configured individually.
–> “Drives” –> Drive name –> Double-click
“Configuration”
–> Click “Configure DDS”
2.1. Control
structure
You can activate the function modules.
You can select the control type.
2.2. Power
section
The Wizard displays the data determined
automatically from the electronic type plate.
Caution
If a sinusoidal filter is
connected, it must be
activated here to prevent it
from being destroyed!
2.3. BiCo power
section
Supply in operation
Control Unit: r0722.4 (digital input 4)
2.4. Drive setting You can select the motor standard (IEC / NEMA)
and power section application (duty cycles).
2.5. Motor You can enter the name of the motor (e.g.
equipment ID).
Enter motor data: Yes
Select motor type “1LAx”.
You can select a standard
motor from the list of motors
or you can enter the motor
data yourself. You can then
select the motor type.
2.6. Motor data You can enter the motor data on the type plate here.
If known, mechanical data for the motor and drive
line can be entered.
Equivalent circuit diagram data: No
If you do not enter any
mechanical data, it is
estimated on the basis of the
data on the type plate.
The equivalent circuit
diagram data is also
estimated on the basis of the
data on the type plate or
determined by means of
automatic motor data
identification.
2.7. Motor brake Here, you can configure the brake and activate the
“Extended brake control” function module.
For more information, see the
Function Manual.
