Preparations for Commissioning
Requirements for commissioning
2-28
E Siemens AG, 2004. All rights reserved
SINAMICS S120 Installation and Start-Up Manual, 12/04 Edition
2.1 Requirements for commissioning
The following are the basic requirements for commissioning a SINAMICS S drive
system:
S STARTER commissioning tool
S PROFIBUS interface
S Wired drive line-up (see Equipment Manual)
The following diagram shows a basic sample configuration with booksize and
chassis components.
ibn_aufbau.vsd
X100
Control
Unit
320
SMC20
X500
X520
Active
Line Module
X200
Single
Motor Module
X200
X100
Control
Unit
320
Active
Interface Module
X500
Single Motor
Module
X400
Active
Line Module
X400 X402
PROFIBUS
X126
PC/PG
PROFIBUS
X126
PC/PG
Booksize
Chassis
Fig. 2-1 Component configuration (example)
