Introduction
1.2 Safety Notes
SITRANS FUH1010 Quick Start
10 Operating Instructions (Compact), 12/2008, CQO:QSG010 Revision A
Quick Start Safety Information for Hazardous Areas
Note
Ratings under this heading apply to specific model families
Check Your Model Number:
FUS1010 7ME3531, FUH1010, 7ME3601, FUG1010 7ME3611 only;
FM-CSA installation
Read, understand and follow all safety instruction on the electronic media provided. This
equipment is rated for use in hazardous (classified) locations as stated below and must be
installed according to the 1010-341 installation drawing provided on the media. Failure to
install the equipment in the prescribed manner will result in unsafe operation. Follow all local
jurisdictional safety codes when operating this equipment. When properly installed the
equipment meets the following FM–CSA ratings:
Flow Meter
● Explosionproof for Class I, Division1, Groups B, C, D;
● Dust-ignitionproof for Class II, Division 1, Groups E, F and G
● Intrinsically safe connections for Class I and II, Division 1, Groups A, B, C, D, E, F and G;
● Nonincendive for Class I, Division 2, Groups A, B, C and D;
● Suitable for Class II Division 2 Groups F and G outdoor (Type 4X)
Transducers
● Intrinsically safe Class I and II, Division 1, Groups A, B, C, D, E, F and G;
● Nonincendive for Class I, Division 2, Groups A, B, C and D;
● Suitable for Class II Division 2 Groups F and G outdoor (Type 4X)
● Temperature code T6 at an ambient of 40°C
ATEX installation
Read, understand and follow all safety instruction on the electronic media provided. This
equipment is rated for use in explosive atmospheres as stated below and must be installed
according to the 1010-422 installation drawing provided on the media. Failure to install the
equipment in the prescribed manner will result in unsafe operation. Follow all regional safety
laws when operating this equipment. When properly installed the equipment meets the
following ATEX ratings as stated in EC-Type Examination Certificate KEMA03ATEX2133

Siemens Sitrans F Series Specifications

General

Measurement Principle	Coriolis, Electromagnetic, Ultrasonic
Communication Protocols	HART, PROFIBUS, Foundation Fieldbus, Modbus
Pressure Range	Varies by model (e.g., up to 400 bar for some models)
Power Supply	24 V DC or 110-230 V AC
Protection Class	IP67, IP68
Housing Material	Stainless steel, aluminum
Liner Material	PTFE, PFA, rubber
Electrode Material	Stainless steel, Hastelloy, platinum
