SITRANS LVS100/200
14 Operating Instructions, 01/2019, A5E44839609-AA
● Installation shall be performed by qualified personnel and in accordance with local
governing regulations.
● Do not bend, shorten or extend the tines.
● Position the tines using a 50 mm open-end wrench when installing the process
connection (do not turn the housing). When side mounting SITRANS LVS100/200,
position the tines vertically, with the tine orientation marking facing up or down.
● In pressure applications, use PTFE tape or other appropriate sealant to seal tapered
threaded connections.
● After mounting, ensure the cable entries point downward to prevent water entering the
housing.
● For the SITRANS LVS100/200 extended model, the torque due to material loading at the
mounting point may not exceed 250 Nm.
● Mounting torque for the 1½" thread connection may not exceed 80 Nm.
•
This product is designated as a Pressure Accessory per Directive 2014/68/EU and is not
intended for use as a safety device.
• Improper installation may result in loss of process pressure.
• To install devices in hazardous locations, observe all valid installation regulations.
• For Dust Ex installations: Before opening the device lid, ensure there are no deposits
present.
• Do not remove lid while circuits are live.
• Install the SITRANS LVS100/200 so mechanical friction or impact does not cause
sparks between the aluminum enclosure and steel vessel.
