WA_DEV_GL6100_PTS_001 Rev 002 May 24, 2010 22
GL61x0 Product Technical
Specification and User Guide
GL61x0 Cables and Accessories
3.2. Standard DB9 Cable (for the GL6100)
This is a standard DB9 to DB9 cable and it comes with the GL6100. Refer to the following figures and
table for the pin assignment and pin description of the standard DB9 cable.
Refer to Table 2: GL61x0 Shipment Configuration to see which shipment configuration of the GL6100
comes with this cable.
Figure 8. DB9 Cable
Figure 9. Pin Assignment of the DB9 Cable
