WA_DEV_GL6100_PTS_001 Rev 002 May 24, 2010 90

GL61x0 Product Technical

Specification and User Guide

Appendix A: Packaging

20.3. GL6110 Package

The GL6110 package contains the following items:

1. GL6110

2. FME Antenna

3. Micro-fit

®

USB Cable

GL6110

FME Antenna

Micro-fit

®

USB Cable
