Power Consumption
12.3. GL6110 Power Consumption
Only one DC input (Vin) was used to measure the GL6110 power consumption. For more information
on the consumption measurement procedure, refer to section 12.4 Consumption Measurement
Procedure.
Note that power consumption performance is software related. The results listed in the following sub-
sections were based on Firmware 7.4a. Refer to section 10.3 Operating System Upgrade Procedure
for more information on upgrading the software.
12.3.1. Power Consumption without the Sierra Wireless
Software Suite
Note: TX = the current peak is the RF transmission burst (Tx burst)
RX = the current peak is the RF reception burst (Rx burst)
Table 48: Power Consumption without the Sierra Wireless Software Suite; Typical Values
Working Modes
Parameters
I
average
Vin = 5V
I
Peak
Unit
Active Idle Mode
Paging 9 (Rx burst occurrence ~2s)
59.259
144.876
mA
Paging 2 (Rx burst occurrence ~0,5s)
59.992
146.254
mA
Active Mode
63.449
71.443
mA
Connected Mode
850/900 MHz
PCL5 (TX power 33dBm)
242.351
465.515
mA
PCL19 (TX power 6dBm)
106.619
202.616
mA
1800/1900 MHz
PCL0 (TX power 33dBm)
157.194
446.294
mA
PCL19 (TX power 6dBm)
81.591
162.252
mA
Transfer Mode class
8 (4Rx/1Tx)
850/900 MHz
PCL3 (TX power 33dBm)
252.735
465.301
mA
PCL17 (TX power 5dBm)
102.5
198.985
mA
1800/1900 MHz
PCL3 (TX power 30dBm)
172.435
446.294
mA
PCL18 (TX power 0dBm)
99.24
175.493
mA
Transfer Mode class
10 (3Rx/2Tx)
850/900 MHz
PCL3 (TX power 33dBm)
453.834
462.525
mA
PCL17 (TX power 5dBm)
132.548
223.545
mA
1800/1900 MHz
PCL3 (TX power 30dBm)
277.077
448.643
mA
PCL18 (TX power 0dBm)
126.106
193.432
mA
