Power Consumption
12.4.2.2. Equipment Configuration
The communication tester is set according to the GL61x0 operating mode. Paging during idle modes,
Tx burst power, RF band and GSM/DCS/GPRS may be selected on the communication tester.
Refer to the following table for the network analyzer configuration according to operating mode.
Table 50: Operating Mode Information
Operating Mode
Communication Tester Configuration
Alarm Mode
N/A
Active Idle Mode
Paging 9 (Rx burst occurrence ~2s)
Paging 2 (Rx burst occurrence ~0,5s)
Sleep Idle Mode
Paging 9 (Rx burst occurrence ~2s)
Paging 2 (Rx burst occurrence ~0,5s)
Active Mode
N/A
Sleep Mode
N/A
Connected Mode
850/900 MHz
PCL5 (TX power 33dBm)
PCL19 (TX power 5dBm)
1800/1900 MHz
PCL0 (TX power 30dBm)
PCL15 (TX power 0dBm)
GPRS
Transfer Mode class 8
(4Rx/1Tx)
850/900 MHz
Gam.3 (TX power 33dBm)
Gam.17 (TX power 5dBm)
1800/1900 MHz
Gam.3 (TX power 30dBm)
Gam.18 (TX power 0dBm)
Transfer Mode class 10
(3Rx/2Tx)
850/900 MHz
Gam.3 (TX power 33dBm)
Gam.17 (TX power 5dBm)
1800/1900 MHz
Gam.3 (TX power 30dBm)
Gam.18 (TX power 0dBm)
