GL61x0 Cables and Accessories
3.3. DC Cable (for the GL6100)
This cable supplies the power source for the GL6100, and is used with the adaptive cable.
Refer to Table 2: GL61x0 Shipment Configuration to see which shipment configuration of the GL6100
comes with this cable.
Figure 10. DC Cable
Figure 11. Pin Assignment of the DC Cable
Table 8: DC Cable Pin Description
