Signal SDS Series User Manual

SDS Series
34
Programming
MANUAL / TEST
MANUALLY START A PROGRAM:
From the current Time
and Date display scroll
MANUAL/TEST
< Press Enter >
Manual Start Prg
< Press Enter >
Use numeric keys
to enter selection
Program %[0-250]
100
Use numeric keys if a
% change is required
Enter Program No?
1
Program Type
< Normal Program >
Use < > to select Normal
Program or HydroSector
Man. Stns M#
Stn No. ## (00 : 00)
If the current Station countdown is not currently displayed, press BACK Go to the
current Time and Date display. “M” will flash indicating manual STNs running;
STOP MANUAL STATIONS:
VIEW MANUAL STATIONS CURRENTLY RUNNING:
To stop a running program, press
MANUALLY START/STOP STATIONS:
MANUAL/TEST
< Press Enter >
Manual Start Prg
< Press Enter >
Use numeric keys
to select m/s
Set Station Time
00 : 00 Ms
Use < > keys to select
different pump option
Set From / End Stn
From ## End ##
Select station numbers
from keypad
Manual Start Stn
< Press Enter >
< Master Pump >
Start Delay 00 : 00
Use numeric keys in min : sec if a delay
is wanted before the manual start begins
and
or
From the current station countdown screen,
simply enter the desired station number, then;
From the current Time
and Date display scroll
SKIP STATIONS FORWARD/BACK:
From here, stations can be skipped
FORWARD/BACK as seen in step above.
Use numeric keys to
select program
