Signal SDS Series User Manual

SDS Series
49
Use < > keys to
view stations
H# Station Delay
00 : 00 Ms
If required use numeric keys to
enter station delay mins : secs.
H# Total Water
00 : 00 : 00
If the auxiliary pump option is used the following will display.
Note. The auxiliary pre-wet is the time the station runs without the dosing pump (auxiliary)
running. The auxiliary run is the dosing pump run time. The balance of the time on the sta-
tions watering time is a post-wash time.
Use keypad to enter auxiliary sta-
tions run times hr:min:sec
Repeat for next
stations
To select DataNode
other than default (50)
Use keypad
to select
<H# Aux. Stn 01>
00 : 00 :00 100%
H# Prewet Delay
00 : 00 Ms
H# Aux. Pump
default
Use keypad to enter
delay time min : sec
CONTROLLER FACTORY DEFAULT RESET:
This resets controller to all factory default settings and clears all programmed entries.
Programming
From the current Time and
Date display< > scroll
SYSTEM SETTINGS
< Press Enter >
Flow Meter pulse
< Press Enter >
Factory Default
< Press Enter >
Key in 1234
Default < 1234 >
WM Config <6021>
