SDS Series
48
AUTO-PROGRAMMING FEATURE:
The auto-programming option assigns time or volume of water to each valve & stn within the
HydroSector from a total value entered for each H/Sector.
If Auto programming is not selected go to Program Entry display and program as normal.
Rewriting Progs
......Please wait
The HydroSectors are now selected. Stations have been allocated and watering times and/
or volumes have automatically been calculated for each valve/station and start times have
been programmed.
Program
< Press Enter >
Program Entry
< Press Enter >
Use numeric keys
to select
Enter Program No?
#
< H# Mode >
Normal
If no loop
prog required
H# Master Pump
Default
H# Water Days
SMTWTFS SMTWTFS
Enter station numbers
from keypad
< Total Water >
H# 00 : 00 : 00 100%
Use numeric keys
and enter time
< Hydro Stations >
H# From ## To ##
Auto programming
< Enabled >
To enable Au-
to-program
To program by
precipitation
< Total Water >
H# ## mm 100%
Use numeric keys and enter mm. Run
time can be checked by pressing on/off
For the volumetric watering option this must be
selected in the Program Entry menu
The next phase enters into each HydroSector its start time acceptances of the 4 master start
times and the 14 day calendar for each of the sectors. Pressing the Back key to Program
display and continue as described in the next section.
Programming
ACTIVE DAYS AND ACCEPTANCE OF MASTER START TIMES:
Use < > keys to
select more starts
< H# Start Time 1 >
None
On/off key to
select starts
< P# Option >
Time
The display will show the time or volumes allocated to
each station. Water volume will be calculated depend-
ing on number of valves allocated to that station
To Next Page
