Signal SDS Series User Manual

SDS Series
41
Programming
VIEW DATANODES:
Use < > keys to scroll to
“View Data Nodes” display
From the “TWO-
WIRE“ menu
View Data Nodes
< Press Enter >
< Add. 01 Add. 02 >
X00 (##) X00 (##)
Use < > keys
to view
ASSIGN NUMBER TO DATANODE / MOISTURE NODE:
To assign a number to the DataNode or Moisture Node, the DataNode must be connected to
the Two-wire Devices Program Port or Mobile Programmer using the supplied leads.
Program DataNodes
< Press Enter >
Use < > keys to scroll to
Program DataNodes display
From the “TWO-
WIRE“ menu
Enter DN Number
00
Use the numeric keys to
enter the DN number
Caution: Ensure programming is correct before disconnecting from the
program port. Once disconnected, the device cannot be reprogrammed
Con’t
Moisture sensor pre-set irrigation override setting, see page 43.
Stop Program this is linked to the Start Program input sensor at the controller i.e. pro-
gram/s started by the Start Program input sensor are stopped by the Stop Program sensor.
see page 42.
