PN 200972-001 Rev B v
Preface
This document provides the authorized replacement procedures for Silver Peak appliances, when
applicable. It also provides specifications and annotated photos or diagrams for interfaces, LEDs, disk
layout, and power cords.
Who Should Read This Manual?
The audience for this document includes, Customer Support, field personnel, and customers using
Silver Peak appliance hardware.
Manual Organization
This section outlines the chapters and summarizes their content.
Chapter 1, “Replacing an HDD or SSD,” provides a table that summarizes information about the drives
in each Silver Peak Appliance. It describes how to remove and add a disk from the database, using the
Appliance Manager. It also illustrates the physical replacement steps.
Chapter 2, “Replacing a Power Supply,” describes the procedures for replacing an authorized, redundant
power supply.
Chapter 3, “Replacing a Fiber Interface Module,” describes the procedures for replacing an SR (or LR)
fiber interface module.
Chapter 4, “Replacing a Deployed Appliance,” provides a checklist for inserting a new appliance to
replace a previously configured one.
Chapter 5, “Specifications, Compliance, and Regulatory Statements,” lists model specification, warning
statements, and compliance statements.
Chapter 6, “Appliance Views,” provides annotated diagrams of each hardware model’s interfaces, LEDs,
and disk layout.
Chapter 7, “Power Cords & Cable Pinouts,” lists and illustrates power cords by country.
