NX-3700 [PN 200400] Chapter 6 Appliance Views
PN 200972-001 Rev B 71
NX-3700 [PN 200400]
NX-3700 HDD Power Supplies
Quantity 2 2
User authorized to replace? yes yes
Hot swappable? yes yes
Power button
[plugging the power cords
in automatically powers
up the appliance]
Power LED [blue = ON]
System reset
Alarm mute
Illuminates red when a power
supply is disconnected or off
NX-3700 — Front View
NX-3700 — Disk Layout
