NX-8600 [PN 200181] Chapter 6 Appliance Views
PN 200972-001 Rev B 85
NX-8600 [PN 200181]
NX-8600 HDD Power Supplies
Quantity 16 3
User authorized to replace? yes yes
Hot swappable? yes yes
Power LED [blue = ON]
NX-8600 — Front View
Not usedAlarm MuteSystem Reset
mgmt0 mgmt1
Disk Drive Drive activity
[Yellow = busy]
NX-8600 — Disk Layout
NX-8600 — Rear View
