SilverPeak EC-XS - Nx-5700 [Pn 200399]

Silver Peak Hardware Reference Guide NX-5700 [PN 200399]
76 PN 200972-001 Rev B
NX-5700 [PN 200399]
NX-5700 HDD Power Supplies
Quantity 8 2
User authorized to replace? yes yes
Hot swappable? yes yes
Power button
[plugging the power cords
in automatically powers
up the appliance]
Power LED [blue = ON]
System reset
Alarm mute
Illuminates red when a power
supply is disconnected or off
NX-5700 — Front View
NX-5700 — Disk Layout
