NX-2700 [PN 200401] Chapter 6 Appliance Views
PN 200972-001 Rev B 67
NX-2700 [PN 200401]
NX-2700 HDD Power Supplies
Quantity 2 2
User authorized to replace? yes yes
Hot swappable? yes yes
Power button
[plugging the power cords
in automatically powers
up the appliance]
Power LED [blue = ON]
System reset
Alarm mute
Illuminates red when a power
supply is disconnected or off
NX-2700 — Front View
NX-2700 — Disk Layout
