Silver Peak Hardware Reference Guide EC-XL [PN 200884]
58 PN 200972-001 Rev B
mgmt0 & mgmt1
Not connected Connected at max speed Connected at lower speed Traffic
1/10 Gbps fiber interfaces for tlan / twan
a
a. These are SR (Short Reach) modules.
Indicator 10G 1G
LNK Link blue solid green solid
ACT Activity green blinking
BYPASS Bypass green solid
DISC Disconnect yellow solid
NRM Normal off — In NRM mode, the ports are independent interfaces
