Silver Peak Hardware Reference Guide NX-8700 [PN 200767]
92 PN 200972-001 Rev B
10 Gbps fiber interfaces
You have the option to separately order LR (Long Reach) 10 Gbps Fiber Interfaces to replace the default
SR (Short Reach) modules in the NX-8700 appliance.
Silver Peak supports different module combinations. For example, you may have an SR (Short
Reach) interface for the LAN side and an LR (or Long Reach) for the WAN.
These modules are hot-swappable.
You can distinguish the SR module from the LR module by the number on the label and the color of the
handle.
NX-8700
tlan0 / twan0
all LEDs are green
Link = solid
Activity = blinking
FTLX8571D3BCL — SR — Short Reach
• Bail (handle) is beige
• Default shipping module
FTLX1471D3BCL — LR — Long Reach
• Bail (handle) is blue
• Optional, separate purchase
