SIM7000 _Hardware Design _V1.04 2018-1-31
Table 3: Pin definition
Pin No.
Pin Name
Pin No.
Pin Name
1 PWRKEY 2 GND
3 DTR 4 RI
5 DCD 6 BOOT_CFG
7
CTS
8
RTS
9 TXD 10 RXD
11 PCM_CLK 12 PCM_SYNC
13 PCM_DIN 14 PCM_DOUT
15 VDD_EXT 16 NRESET
17 GND 18 GND
19 NC 20 NC
21 NC 22 NC
23 MDM_LOG_TX 24 USB_VBUS
25
ADC
26
NC
27 USB_DP 28 USB_DM
29 GND 30 SIM_VDD
31 SIM _ D ATA 32 SIM_CLK
33 SIM_RST 34 SIM_DET
35 NC 36 NC
37
I2C_SDA
38
I2C_SCL
39 GND 40 NC
41
NC
42
NC
43
NC
44
NC
45 GND 46 GND
47 NC 48 GPIO4
49 GPIO1/UART3_RXD 50 GPIO0/UART3_TXD
51
NC
52
NETLIGHT
53
GNSS_ANT
54
GND
55 VBAT 56 VBAT
57 VBAT 58 GND
59 GND 60 RF_ANT
61 GND 62 GND
63
GND
64
GND
65 GND 66 S TATU S
67 GPIO2 68 GPIO3
NOTE: Before the normal power up, BOOT_CFG cannot be pulled up.
