C. Coding Schemes and Maximum Net Data Rates over Air Interface
Table 43: Coding Schemes and Maximum Net Data Rates over Air Interface
Multi slot definition(GPRS/EDGE)
Slot class DL slot number UL slot number Active slot number
1
1
1
2
2
2
1
3
3
2
2
3
4
3
1
4
5
2
2
4
6
3
2
4
7
3
3
4
8
4
1
5
9
3
2
5
10
4
2
5
11
4
3
5
12
4
4
5
GPRS coding scheme
Max data rata
（
4 slots
）
Modulation type
CS 1 = 9.05 kb/s / time slot
36.2 kb/s
GMSK
CS 2 = 13.4 kb/s / time slot
53.6 kb/s
GMSK
CS 3 = 15.6 kb/s / time slot
62.4 kb/s
GMSK
CS 4 = 21.4 kb/s / time slot
85.6 kb/s
GMSK
EDGE coding scheme
Max data rata
（
4 slots
）
Modulation type
MCS 1 = 8.8 kb/s/ time slot
35.2 kb/s
GMSK
MCS 2 = 11.2 kb/s/ time slot
44.8 kb/s
GMSK
MCS 3 = 14.8 kb/s/ time slot
59.2 kb/s
GMSK
MCS 4 = 17.6 kb/s/ time slot
70.4 kb/s
GMSK
MCS 5 = 22.4 kb/s/ time slot
89.6 kb/s
8PSK
MCS 6 = 29.6 kb/s/ time slot
118.4 kb/s
8PSK
MCS 7 = 44.8 kb/s/ time slot
179.2 kb/s
8PSK
MCS 8 = 54.4 kb/s/ time slot
217.6 kb/s
8PSK
MCS 9 = 59.2 kb/s/ time slot
236.8 kb/s
8PSK
LTE -FDD device category
(Downlink)
Max data rate
（
peak
）
Modulation type
Category 1 10Mbps
QPSK/16QAM/64Q
AM
Category 2 50Mbps
QPSK/16QAM/64Q
AM
Category 3 100Mbps
QPSK/16QAM/64Q
AM
Category 4 150Mbps
QPSK/16QAM/64Q
AM
LTE -FDD device category
(Uplink)
Max data rate
（
peak
）
Modulation type
Category 1
5Mbps
QPSK/16QAM
