4 RF Specifications
4.1 GSM/LTE RF Specifications
Table 19: Conducted transmission power
Frequency
Power
Min.
EGSM900
33dBm ±2dB
5dBm ± 5dB
DCS1800
30dBm ±2dB
0dBm ± 5dB
LT E -FDD B1
23dBm +/-2.7dB
<-40dBm
LT E -FDD B2
23dBm +/-2.7dB
<-40dBm
LT E -FDD B3
23dBm +/-2.7dB
<-40dBm
LT E -FDD B4
23dBm +/-2.7dB
<-40dBm
LT E -FDD B5
23dBm +/-2.7dB
<-40dBm
LT E -FDD B6
23dBm +/-2.7dB
<-40dBm
LT E -FDD B8
23dBm +/-2.7dB
<-40dBm
LT E -FDD B12
23dBm +/-2.7dB
<-40dBm
LT E -FDD B13
23dBm +/-2.7dB
<-40dBm
LT E -FDD B18
23dBm +/-2.7dB
<-40dBm
LT E -FDD B19
23dBm +/-2.7dB
<-40dBm
LT E -FDD B20
23dBm +/-2.7dB
<-40dBm
LT E -FDD B26
23dBm +/-2.7dB
<-40dBm
LT E -FDD B28
23dBm +/-2.7dB
<-40dBm
LT E -FDD B39
23dBm +/-2.7dB
<-40dBm
* Note ： The max power is tested result for 1RB in CAT-M1 and single-tone in CAT-NB1. MPR
for CAT-M1 please refer to 6.2.3EA.5 part for 3GPP. Multi-tone test results please refer to part
6.2.3F.3 for CAT-NB1.
Table 20: Maximum Power Reduction (MPR) for UE category NB1 Power Class 3
Modulation
QPSK
Tone positions for 3
Tones allocation
0-2 3-5 and 6-8 9-11
MPR
≤ 0.5 dB
0 dB
≤ 0.5 dB
Tone positions for 6
Tones allocation
0-5 and 6-11
MPR
≤ 1 dB
≤ 1 dB
Tone positions for 12
Tones allocation
0-11
MPR ≤ 2 dB
