Table 24: CAT-M1 Reference sensitivity (QPSK)
E-UTRA Band
REFSENS MAX(dBm)
3GPP
REFSENS
Typical (dBm)
Duplex Mode
1 -103 -108 HD-FDD
2
-101
-107.5
HD-FDD
3
-100
-108.5
HD-FDD
4
-103
-108
HD-FDD
5
-101.5
-107
HD-FDD
8 -100.5 -107.5 HD-FDD
12 -100 -107 HD-FDD
13 -100 -107 HD-FDD
18 -103 -108 HD-FDD
19 -103 -108 HD-FDD
20 -100.5 -108.5 HD-FDD
26
-101
-107.5
HD-FDD
28 -101.5 -107 HD-FDD
39 -103.7 TBD TDD
Table 25: CAT-NB1 Reference sensitivity (QPSK)
Operating band
REFSENS
(dBm) 3GPP
Request
REFSENS
Typical(dBm)
REFSENS Typical
Repeated 7/128
[EPRE dBm/15KHz]
1, 2, 3, 4,5, 8, 12, 13, 17, 18, 19, 20, 26, 28 -108.2 -114 -145
