SimCom SIM7000 User Manual

Smart Machine Smart Decision
SIM7000 _Hardware Design _V1.04 2018-1-31
@10dbm Typical: 110mA
@0dbm Typical: 102 mA
LT E -FDD B4
@23dbm Typical: 150mA
@10dbm Typica : 114mA
@0dbm Typical: 102mA
LT E -FDD B5
@23dbm Typical: 168mA
@10dbm Typical: 117mA
@0dbm Typical: 113mA
LT E -FDD B8
@23dbm Typical: 165mA
@10dbm Typical: 110mA
@0dbm Typical: 98mA
LT E -FDD B12
@23dbm Typical: 167mA
@10dbm Typical: 109mA
@0dbm Typical: 96mA
LT E -FDD B13
@23dbm Typical: 168mA
@10dbm Typical: 114mA
@0dbm Typical: 97mA
LT E -FDD B18
@23dbm Typical: 167mA
@10dbm Typical: 109mA
@0dbm Typical: 98mA
LT E -FDD B19
@23dbm Typical: 171mA
@10dbm Typical: 110mA
@0dbm Typical: 99mA
LT E -FDD B20
@23dbm Typical: 167mA
@10dbm Typical: 110mA
@0dbm Typical: 98mA
LT E -FDD B26
@23dbm Typical: 168mA
@10dbm Typical: 109mA
@0dbm Typical: 98mA
LT E -FDD B28
@23dbm Typical: 195mA
@10dbm Typical: 135mA
@0dbm Typical: 115mA
LTE Cat-NB data transmission
B5
UL mac padding _15KHZ_1RU_1 subcarrier_0dbm
59.94 mA
UL mac padding _15KHZ_1RU_1 subcarrier_10dbm
68.48 mA
UL mac padding _15KHZ_1RU_1 subcarrier_23dbm
143.22 mA
UL mac padding _3.75KHZ_1RU_1 subcarrier_0dbm
83.60 mA
UL mac padding _3.75KHZ_1RU_1 subcarrier_10dbm
100.03 mA
UL mac padding _3.75KHZ_1RU_1 subcarrier_23dbm
244.96 mA
UL mac padding _15KHZ_12subcarrier_23dbm
92mA
DL mac padding _15KHZ_12subcarrier_23dbm
66.42mA
B8
UL mac padding _15KHZ_1RU_1 subcarrier_0dbm
60.42 mA
UL mac padding _15KHZ_1RU_1 subcarrier_10dbm
69.54 mA
UL mac padding _15KHZ_1RU_1 subcarrier_23dbm
144.60 mA
UL mac padding _3.75KHZ_1RU_1 subcarrier_0dbm
83.84 mA
UL mac padding _3.75KHZ_1RU_1 subcarrier_10dbm
101.37 mA
UL mac padding _3.75KHZ_1RU_1 subcarrier_23dbm
248.67 mA
UL mac padding _15KHZ_12subcarrier_23dbm
93mA
DL mac padding _15KHZ_12subcarrier_23dbm
68.4mA
SIMCOM CONFIDENTIAL FILE
