Power down mode 38 50 uA
Sleep mode (AT+CFUN=1):
( BS-PA-MFRMS=9 )
( BS-PA-MFRMS=5)
( BS-PA-MFRMS=2)
1.965
1.7
1.4
mA
mA
mA
Idle mode (AT+CFUN=1):
EGSM900 22.1 mA
Voice call (PCL=5):
GSM850
EGSM900
DCS1800
PCS1900
207.63
202.32
139.825
137.805
mA
mA
Data mode GPRS (1Rx,4Tx):
GSM850
EGSM900
DCS1800
PCS1900
445.82
424.32
293.62
279.18
mA
mA
Data mode GPRS (3Rx,2Tx):
GSM850
EGSM900
DCS1800
PCS1900
329.79
220.62
223.18
218.34
mA
mA
I
VBAT
Average current
Data mode GPRS (4Rx,1Tx):
GSM850
EGSM900
DCS1800
PCS1900
221.25
220.62
158.01
158.62
mA
mA
I
MAX
Peak current During TX burst 2.0 A
* In above table the current consumption value is the typical one of the module tested in laboratory. In the mass production stage,
there may be differences among each individual.
6.9 Electro-Static Discharge
SIM808 is an ESD sensitive component, so more attention should be paid to the procedure of handling and
packaging. The ESD test results are shown in the following table.
Table
46: The ESD characteristics (Temperature: 25℃, Humidity: 45 %)
Pin Contact discharge Air discharge
VBAT ±5KV ±10KV
GND ±5KV ±10KV
RXD, TXD ±4KV ±8KV
Antenna port ±5KV ±10KV
