10 OVERVIEW OF END-USER PARAMETERS
Line Function Range Unit Resolution Factory setting
Setting the clock
1 Time of day 0...23:59 h/min 1 min –
2 Weekday 1...7 day 1 day –
3 Date (day, month) 01.01...31.12 day month 1 _
4 Year 1999...2099 year 1 _
Time switch program for heating circuit
5 Weekday-preselection heating circuit 1-7 / 1...7 day 1 day –
1-7 7 - day block 1…7 Individual days
6 Switch-on time 1. 3rd period heating circuit 00:00...23:59 h/min 10 min 06:00
7 Switch-off time 1. 3rd period heating circuit 00:00...23:59 h/min 10 min 22:00
8 Switch-on time 2. 3rd period heating circuit 00:00...23:59 h/min 10 min ––:––
9 Switch-off time 2. 3rd period heating circuit 00:00...23:59 h/min 10 min ––:––
10 Switch-on time 3. 3rd period heating circuit 00:00...23:59 h/min 10 min ––:––
11 Switch-off time 3. 3rd period heating circuit 00:00...23:59 h/min 10 min ––:––
D.h.w. values
13 Nominal setpoint of d.h.w. temperature (TBWw) TBWR...TBWmax °C 1 55
TBWR – Line 120
TBWmax - Line 40 (OEM)
Heating circuit values
14 Reduced setpoint of room temperature (TRRw) TRF...TRN °C 0.5 16
TRF - Line 15
TRN - Setpoint knob
15 Frost protection setpoint of room temperature (TRFw) 4...TRR °C 0.5 10
TRR - Line14
16 Summer / winter changeover temperature 8...30 °C 0.5 17
17 Slope of heating curve –:–– / 2.5...40 – 0.5 15
–.–– Inactive 2.5...40 Active
Actual values
18 Actual value of room temperature (TRx) 0...50 °C 0.5 –
19 Actual value of outside temperature (TAx) –50...+50 °C 0.5 –
To set the attenuated outside temperature to Tax
press the plus and min. buttons simultaneously for 3 sec..
Maintenance
23 Standard time program for heating circuit and d.h.w. 0/1 (OFF/ON) – 1 0
To activate, press the plus and minus buttons
simultaneously for 3 seconds
Time switch program for d.h.w. heating
29 Preselection of weekday 1-7 / 1...7 day 1 day –
1-7 day block 1...7 Individual days
30 Switch-on time 1. 3rd period d.h.w. 00:00...23:59 h/min 10 min 06:00
31 Switch-off time 1. 3rd period d.h.w. 00:00...23:59 h/min 10 min 22:00
32 Switch-on time 2. 3rd period d.h.w. 00:00...23:59 h/min 10 min ––:––
33 Switch-off time 2. 3rd period d.h.w. 00:00...23:59 h/min 10 min ––:––
34 Switch-on time 3. 3rd period d.h.w. 00:00...23:59 h/min 10 min ––:––
35 Switch-off time 3. 3rd period d.h.w. 00:00...23:59 h/min 10 min ––:––
Service
50 Indication of faults 0...255 /
00.01-14.16 – 1 –
