7.9.5.6. Thermocouples sensor measurement modules
The
TC
modules are equipped with four, eight or twelve thermocouple inputs and one
input for connectors temperature measurement, see
Appendices 8.6. TC4, TC8, TC12 –
THERMOCOUPLE SENSOR MEASUREMENT MODULES
. The primary destination of this
module is temperature measurement using thermocouple sensors, but it is also possible to
measure voltage in typical thermocouple ranges.
The TC modules parameters are:
–
Name
– each built-in input already has a name given by the device and the user
cannot change it, for the description of the
Name
parameter see
Fig. 7.81
,
–
Unit
– parameter which displays
°C
or
mV
, depending on the
Mode
parameter
settings,
–
Mode
– allows to set a thermocouple which is used for measurements or voltage
measurement range,
–
Low limit
– defines the measurement level below which the
Lo
state will be
displayed in the logical channel,
–
High limit
– defines the measurement level above which the
Hi
state will be
displayed in the logical channel,
–
Wire compensation
– the menu which allows to compensate measurement errors,
which can be caused by wrong sensor readings,
•
Compensation mode
– allows to choose the parameter which will be used in
the compensation process,
◦
disable
– compensation is not active,
◦
manual
– allows to compensate the sensor constant offset,
–
Compensation
– the parameter which allows to manually compensate
a sensor error, written here the value written here will be added or
subtracted from the measured sensor value,
◦
automatic
– allows to compensate the difference between the real
temperature and that measured by the sensor,
–
Actual temperature
– the parameter in which the user enters the
current temperature near the sensor, which is measured with a more
reliable thermometer,
–
Compensate
– the button which activates the compensation; the value
which is written in the
Actual temperature
parameter will be from now
on used for compensation,
–
Compensation
– a read only parameter; displays the voltage value
calculated to compensate the temperature measurement,
The user should remember that after changing the sensor new settings in the
Wire
compensation
menu should be made.
The connectors temperature input parameters are:
–
Name
– each built-in input already has a name given by the device and the user
cannot change it, for the description of the
Name
parameter see
Fig. 7.81
,
–
Unit
– the parameter which displays
°C
,
–
Mode
– the parameter which displays “
Temp. of connectors
”,
–
Low limit
– defines the measurement level below which the
Lo
state will be
displayed in the logical channel,
–
High limit
– defines the measurement level above which the
Hi
state will be
displayed in the logical channel,
157
