device in form of a list. The list format is described in
chapter 8.17. DATA FORMAT
in paragraph
Detailed description of files
.
8.19.2. Documentation
Contains manual of the device and instructions about the hardest functionalities of the
device which can trouble the user the most.
Following submenus can be found here:
–
User manual
– allows to download the manual which is stored in the device's
memory. In order to do this in submenu the user should press “
Proceed
” button,
select a language and press the “
Download
” button.
–
Remote display manual
– opens the description of a net hardware configuration
with the
MultiCon CMC-99/141
to link with the remote display.
–
Network interface description
– contains the description of a direct access to log
files (in the device has active log option) using HTTP protocol.
– Data format – contains log files format description. Full description is also in
chapter
8.17. DATA FORMAT
.
More information can be found in
chapter 7.4. DEVICE INFORMATION, LICENCE,
FIRMWARE UPDATE, REMOTE DISPLAY, EXPORT MANUAL AND RENEW
CONFIGURATION
and
8.18. DIRECT ACCESS TO LOG FILES USING HTTP PROTOCOL
.
8.19.3. Logging and User menu
Most of the options available via www page are available without logging to the device.
But access to option which can change the way that the device work are available after
logging.
If the device has the
Access mode: single level
or
Access mode: Multilevel
password
set then the user can login to the device via fields in upper right corner of the screen. On the
screen the
User menu
will appear which has following submenus:
Following submenus can be found here:
–
Remote display
– allows to switch local screen of the device into remote display
without necessity of coming to the device each time. After entering the submenu,
an address of the user's computer where the www page is open will appear in the
IP address
field. This address should be entered in
IP Address
in
Access options
menu in the device. Before switching to remote display it is necessary to check that
the
Xming
is running and configured properly. Pressing the “
Start
” button will switch
from local to remote display. This function is active only for the
Administrator
user
and to those users who have access to
Remote display
option in
Permissions
menu.
–
File management
– allows to export and import configuration and templates of the
device and also to remotely delete all logs from memory.
• In
Export
part the user can download main configuration (
Main config
),
Modbus master templates (
Modbus template
) and Modbus slave templates
(
Modbus slave template
) by choosing particular option and pressing
the “
Download
” button.
• In
Import
part the user can upload main configuration (
Main config
), Modbus
master templates (
Modbus template
) and Modbus slave templates (
Modbus
330
