immediate ON
- means that in times of an alarm state the device immediately
switches the output to high state,
•
timed OFF
- means that in times of an alarm state the device switches the
output to low state after a time delay set in the
Timing
parameter block,
•
timed ON
- means that in times of an alarm state the device switches the output
to low state after a time delay set in the
Timing
parameter block,
• for the
PWM
mode in the
SSR relay
module instead of the
Alarm state
parameter there is the
Alarm level
parameter which allows the user to enter
a value at the output in times of an alarm state (for more information see
Chapter 7.10.3. Built-in output - PWM (Pulse-width modulation) mode for
SSR relay output
),
–
Levels
block parameter - these parameters allow the user to set a range of changes
of the output depending on the input signal, discussed below in this
Chapter
,
–
Timing
parameter block - these parameters allow the user to set a delay time
change of the output state and minimum duration of the output state, discussed
below in this
Chapter
,
For
Built-in outputs
: Relays, Sound signal and Virtual relays, the
low state
is
value
'0'
and the
high state
is value
'1'
.
The manufacturer discourages forcing relays state changes more often than every
second because of their inertia. If the user does it anyway, the relay might not
react to signal changes.
Levels
parameter block (see
Fig. 7.87
,
Fig. 7.88
and
Fig. 7.89
)
These parameters depend on the
Mode
parameter. The parameters are:
–
Level mode
– has 2 options:
•
value
– means that the level will be defined as a constant value,
•
channel
– means that the level will be defined as a logical channel,
–
Level
– this parameter defines a constant signal level exceeding which will cause
an output state change (for
Level mode
:
value
), or allows to choose a logical
channel whose current value will be the threshold for output state changes (for
Level
mode
:
channel
); occurs for
Mode
:
•
above level
– if
Source
value is higher than
Level
value, a high state appears
on the output,
•
below level
– if
Source
value is lower than
Level
value, a low state appears on
the output ,
–
Lower level
and
Upper level
- these parameters define the range at which output
state changes occur (for
Level mode
:
value
), or they allow to choose a logical
channel whose current value will be the range for output state changes (for
Level mode
:
channel
); occurs for
Mode
:
•
inside range
– if the input data is within the defined range, a high state appears
at the output,
•
outside range
– if the input data is outside the defined range, a high state
appears at the output,
–
Hysteresis
– by defining this parameter the user can move the level for changes in
the output state (see
Fig. 7.87
and
Fig. 7.88
),
–
Alarm level
– this parameter is only visible for the
PWM
mode, allows the user to
enter the value of fill of the pulse in times of an alarm state (for more information see
Chapter 7.10.3. Built-in output - PWM (Pulse-width modulation) mode for SSR
166
