Simex MultiCon CMC-99/141 User Manual

User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Solution:
To complete the task a logical channel in the Profile/timer Mode will be needed:
– touch the screen and press the
Menu
button,
– press the
Device configuration
button,
– enter the
Profiles/timers
menu,
– using the arrows in the top navigation bar, select any
Profile/timer
such as
1
,
– in the
Name
parameter write
Waveform generator
,
–
Triggering mode
parameter set as
on time
,
– enter the
Triggering times
submenu,
•
enter the
Months
menu and press the icon at the bottom left side of the
screen,
•
enter the
Days
menu and press the icon at the bottom left side of the
screen,
•
enter the
Week days
menu and press the icon at the bottom left side of the
screen,
•
enter the
Hours
menu and press the icon at the bottom left side of the
screen,
•
enter the
Minutes
menu and press the icon at the bottom left side of the
screen,
•
enter the
Seconds
menu and press the icon at the bottom left side of the
screen,
– enter the
Section list
submenu,
•
press the green plus at the bottom left side of the screen to configure
Section num.1
:
◦ in
Duration
parameter write
0.2
sec.,
◦
Unit
parameters set as
second
,
◦
Shape
parameter set as
const.value
,
◦ in
Final value
parameter write
1
,
•
press the green plus at the bottom left side of the screen to configure
Section num.2
:
◦ in
Duration
parameter write
1.8
sec.,
◦
Unit
parameters set as
second
,
◦
Shape
parameter set as
const.value
,
◦ in
Final
value parameter write
0
,
–
Looping
parameter set as
infinite
,
–
Return to position
parameter set as
1.Const.val.1(0.2 sec.)
,
– leave the
Profiles/timers
menu and enter the
Logical channels
menu,
– using the arrows in the top navigation bar, select the
Logical channel 3
,
– in
Name
parameter write
Waveform generator
,
–
Mode
parameter set as
Profile/timer
,
–
Source
parameter set as
P/T1:”Waveform generator”
,
– for
Displaying
block parameters:
•
in
Graph low
parameter write
-1
,
•
in
Graph high
parameter write
2
,
198
