Selected background –
displays the name of the file that is currently the
background for the group,
–
Slots
– this button refers to the configuration of the individual slots. View the
submenu presented in
Fig. 7.146
. It allows the user to access the parameters
determining the way of presenting results:
The arrows in the top right corner of the screen allow the user to switch
between slots. The middle button allows the user to directly select a
particular slot from the list.
•
Channel –
indicates the channel for which the display parameters are
configured on the slot,
•
Indicator type –
parameter specifying the form of data presentation, the options
available include:
◦
value –
value of the logical channel displayed as a number,
◦
needle –
value of the logical channel displayed as a needle,
◦ bar –
value of the logical channel displayed as a bar,
•
Dimensions [px]
– parameter defining indicator dimensions. All the indicators
have been presented in
Tab. 7.7
,
If the
Indicator type
parameter is set to
value
, the dimensions available
include:
◦ 54x33 (6 digits),
◦ 64x34 (6 digits),
◦ 80x38 (6 digits),
◦ 80x46 (6 digits),
◦ 100x50 (6 digits),
◦ 160x100 (6 digits),
If the
Indicator type
parameter is set to
needle
, the dimensions available
include:
◦ 73x96 (4 digits),
◦ 100x87 (5 digits),
◦ 106x100 (6 digits),
◦ 123x87 (6 digits),
◦ 161x101 (6 digits),
◦ 160x202 (6 digits),
If the
Indicator type
parameter is set to
bar
, the dimensions available include:
◦ 54x100 (6 digits),
◦ 54x150 (6 digits),
◦ 75x150 (6 digits),
◦ 100x150 (6 digits),
◦ 54x202 (6 digits),
◦ 75x202 (6 digits),
◦ 100x202 (6 digits),
229
