Simex MultiCon CMC-99/141 User Manual

User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Register Write Range Register description
20h No 0÷255
Address of device
21h No 2050h, 2060h
Device identification code
2050h
- device in big housing (5.7” display),
2060h
- device in small housing (3.5” display).
Measurements results (floating point format)
1
200h Yes 0÷0FFFFh
Measurement result for logical channel 1 (high word)
201h Yes 0÷0FFFFh
Measurement result for logical channel 1 (low word)
202h Yes 0÷0FFFFh
Status for logical channel 1:
0h
- data valid,
1h
- data not ready,
20h
- software error,
40h
- bottom border of the software measurement range is
exceeded,
80h
- top border of the software measurement range is exceeded,
2000h
- hardware error,
4000h
- bottom border of the hardware measurement range is
exceeded,
8000h
- top border of the hardware measurement range is
exceeded,
FFFFh
- data not available (e.g. logical channel not configured)
203h Yes 0÷4
Decimal point for logical channel 1
Register from 204h to 2F0h
Measurement results, status and decimal point for Logical
Channels 2÷60
Measurements results (integer format)
1
400h No 0÷0FFFFh
Measurement result for logical channel 1 (high word, not
considering the decimal point)
401h No 0÷0FFFFh
Measurement result for logical channel 1 (low word)
402h No 0÷0FFFFh
Status for logical channel 1:
0h
- data valid,
1h
- data not ready,
20h
- software error,
40h
- bottom border of the software measurement range is
exceeded,
80h
- top border of the software measurement range is exceeded,
2000h
- hardware error,
4000h
- bottom border of the hardware measurement range is
exceeded,
8000h
- top border of the hardware measurement range is
exceeded,
FFFFh
- data not available (e.g. logical channel not configured)
403h No 0÷4
Decimal point for logical channel 1
Register from 404h to 4F0h
Measurement results, status and decimal point for Logical
Channels 2÷60
1
IEEE 754 standard, Float point format represents data as precise as possible. Integer 32 represents value with
constant precision,selected by decimal point position. When decimal is set for example 0.0 then Int32 format represents
240
