Simex MultiCon CMC-99/141 User Manual

User Manual For - CONTROLLER/DATA RECORDER MultiCon CMC-99/141
Most important parameters of
UN3
and
UN5
modules:
UN3 UN5
Number of inputs 3 5
Hardware limitations
current inputs
voltage inputs
thermocouple inputs
RTD inputs
-2mA ÷ 30mA
-1V÷ 12V
-15÷30mV
-15÷120mV
-50÷650mV
-15mV ÷ 30mV
-15mV ÷ 120mV
0÷325Ω,
0÷3250Ω,
-2mA ÷ 30mA
-1V÷ 12V
-15÷30mV
-15÷120mV
-50÷650mV
-15mV ÷ 30mV
-15mV ÷ 120mV
0÷325Ω,
0÷3250Ω,
Hardware resolution:
current inputs
voltage inputs
for range -1÷12 V
for range -15÷30 mV
for range -15÷120 mV
for range -50÷650 mV
thermocouple inputs
range -15mV ÷ 30mV
range -15mV ÷ 120mV
RTD inputs
range 0÷325Ω
range 0÷3250Ω
1mA
1 mV
2 mV
4 mV
40 mV
2mV
4mV
0.01Ω
0.2Ω
1mA
1 mV
2 mV
4 mV
40 mV
2mV
4mV
0.01Ω
0.2Ω
Permissible Long time overload 20% 20%
Covered MultiCon CMC-99/141
measurement ranges *
current inputs
voltage inputs
type max type max
0÷20mA
4÷20mA
0÷5V
1÷5V
0÷10V
2÷10V
-10÷25mV
-10÷100mV
0÷600mV
0÷22mA
4÷22mA
0÷6V
0÷6V
0÷12V
0÷12V
-10÷30mV
-10÷120mV
-50÷650mV
0÷20mA
4÷20mA
0÷5V
1÷5V
0÷10V
2÷10V
-10÷25mV
-10÷100mV
0÷600mV
0÷22mA
4÷22mA
0÷6V
0÷6V
0÷12V
0÷12V
-10÷30mV
-10÷120mV
-50÷650mV
286
