1. WaveNet input starts a timer event.
2. Timer event starts after event expires and starts reaction.
3. Reaction sends the RingCast command to all specified locking devices.
Event at e.g. input 1 of the RouterNode is forwarded to LSM
Launches
timer event
Timer event
waits after
start for X minutes
Event at input 2 is forwarded to LSM
(Trigger: Closed RingCast of input 1 switches output 1, which is connected to input 2)
Ends timer event if X minutes are not yet up
Timer event calls for response if not aborted by event at input 2
Response executed by the LSM or CommNode server
Identical with ring-cast command, e.g. gunman attack
Repeating the broadcast
ü LSM open.
1. Via |Network| select the entry Event manager .
9 The window "Network event manager" opens.
2. In the area "Reactions" click the button New .
9 The window "New reaction" opens.
WaveNet (Manual)
5. WaveNet Manager
117 / 210
