User 1
LSM-GUI
User 2
LSM-GUI
User 3
LSM-GUI
Internet/Intranet
(TCP/IP)
Server
Database
Communication nodes
(CommNode)
RS-485
RouterNode
(Cable/Radio)
RouterNode
(868 MHz)
RouterNode
(Ethernet/Radio)
SmartRelay
SmartRelay 2
SmartHandle AX
SmartHandle
Cylinder
Padlock
WaveNet is a dedicated network that you can install and use in building
automation with just a few cables. If you want to retrofit WaveNet, you can
also use existing building networks such as a LAN. This is why WaveNet is
not only suitable for equipping new buildings with a locking system (e.g. for
flexibly used room units). WaveNet is also particularly suitable if you want
to manage and control your existing SimonsVoss 3060 locking system
online in existing buildings.
Networking types can be freely combined with one another as an
alternative to full networking. For instance, you can virtually network the
doors of the outer shell (= building envelope) and particularly critical locks
(for example on server room doors) with your WaveNet and all other
locking devices.
You can choose from various devices and transmission media depending
on your specific situation (see
Transmission paths [}13]
). Data
transmission in WaveNet largely depends on the transmission medium.
With your WaveNet and the IO functions (see
I/O configuration and
protection functions [}68]
), you can optimise security or the precautions
against danger levels far beyond the level of a mechanical locking system.
NOTE
WaveNet training and planning
WaveNet is a comprehensive solution that can be very well tailored to your
requirements. If you want to fully exploit the potential of your WaveNet,
you can attend a SimonsVoss Technologies GmbH
WaveNet training
course. You can also plan your WaveNet project together with a Simons-
Voss technician and benefit from their many years of experience.
WaveNet (Manual)
4. WaveNet system
12 / 210
