Further information on the devices, locks and LSM software can be found in
the relevant manuals and quick guides on the SimonsVoss website
(
https://www.simons-voss.com/
) in the download area under Documents.
4.1 Transmission paths
The WaveNet transfers data from the locking devices to a central
administration, including:
Authorisations
Status changes
protective functions
You can transmit this data using various transmission paths (availability of
devices for certain transmission media may vary).
WaveNet
Wireless
Cable
B-field
SRD*
Ethernet
Serial
25 kHz
868 MHz
TCP/IP
RS-485
*SRD=Short Range Device
25 kHz
B field for communication between:
Transponders and locking
devices
External LockNodes and locking
devices
868 MHz
SRD field for communication
between:
RouterNodes and LockNodes
RouterNodes and RouterNodes
Ethernet
Ethernet cabling for communication
between:
Computer and RouterNodes
WaveNet (Manual)
4. WaveNet system
13 / 210
