SimonsVoss WaveNet - LockNode Specifications

WNM.RN.EC.IO
transfer media Interfaces Power supply Dimensions
 Ethernet
 RS-485
 connecting terminals for
an external plug-in
power supply
 Connection terminals for
RS-485
 RJ45 socket (Ethernet)
 Molex PicoBlade 10-pin
(IO connector)
9V
DC
to 12V
DC
, min. 3VA or
PoE in acc. with IEEE
802.3af, 3W
98×64×40mm
8.3 LockNodes
WNM.LN.I
transfer media Interfaces Power supply Dimensions
 868MHz
Contacts for locking devices Supply from locking device
Integrated in cyl-
inder
WNM.LN.I.S2
transfer media Interfaces Power supply Dimensions
 868MHz
Contacts for locking devices Supply from locking device
Integrated in
SmartHandle AX
WNM.LN.I.SH
transfer media Interfaces Power supply Dimensions
 868MHz
Contacts for locking devices Supply from locking device
Integrated in
SmartHandle
3062
WNM.LN.I.SREL2.G2
transfer media Interfaces Power supply Dimensions
 868MHz
Contacts for locking devices Supply from locking device
Integrated in
SmartRelay 2
(G2)
WNM.LN.I.SREL.G2
transfer media Interfaces Power supply Dimensions
 868MHz
Contacts for locking devices Supply from locking device
Integrated in
SmartRelay (G2)
WaveNet (Manual)
8. Technical specifications
207 / 210
